8110E

For laden container handling with rail mounted or rubber tyred gantry cranes

Product information

Spreader Model 8110E is an all-electric telescopic top lift spreader for handling of laden 20-40ft ISO containers up to 41 tonnes. 8110E is designed for mounting on Automatic Rail Mounted (ARMG), Rail Mounted (RMG) or Rubber Tyred Gantry (RTG) cranes.

The strong and basic concept with a mechanical base design proven for >30 years gives very high reliability regard to fatigue, in-directly the spreader lifetime as well as spreader functionality.

The mainframe with two parallel telescopic beams, assures both maximum overlap and enhanced visibility for the crane driver. Thanks to the extension beam box design not only vertical but also the very considerable horizontal forces are well absorbed.

Standard supply includes

Mounting arrangement to fit crane

Mechanical pile slope

Four pendular ISO twistlocks

Lifting eyes near twistlocks

Type of application	RTG, RMG, ARMG
Spreader weight (TW)	7 700 kg without extra equipment
Lifting capacity (SWL), spreader	41 tonnes ± 10% eccentric load
Lifting capacity (SWL), lifting eyes	4 x 10 tonnes
Twistlock	ISO pendular 20 mm
Telescopic positions	20ft, 30ft, 40ft and B7
Telescoping speed 20-40ft	< 22 sec
Power supply	400 VAC/50 Hz
Electrical motors	1 x 4 kW, 2 x 0,37 kW
Electric - control voltage	24 VDC
Colour	Signal yellow RAL 1003
Paint thickness	220 μ

DISCLAIMER
All specifications are subject to change without notice. A list of options enables you to adapt the product more precisely to your needs and further information is available on request.
